The thickness of steel cover, steel bar position and steel bar spacing are displayed on the same screen;
The measuring range is increased by 15mm, the underlying algorithm is optimized, and the measurement depth is greater;
The dense reinforcement algorithm of the positioning mode is upgraded to effectively eliminate the interference of stirrups;
Optimize dense waveform detection, the accuracy of the number of steel bars and the thickness of the protective layer is greatly improved, and 3 steel bars
can be measured side by side;
Reverse detection function, automatically calculates the correction value according to the complex working conditions on site, and compensates the data
deviation of the protective layer;
The thickness measurement mode is upgraded, the accuracy of the protective layer is 0.1mm, it supports left and right dual-channel AD value prompts, and
the center is automatically interpreted;
Horizontal and vertical laser positioning, real-time display of the steel bar position and the center line of adjacent steel bars, multiple reminders of the aiming
frame and indicator lights, convenient for steel bar positioning and drilling and coring;
Plug-in high-capacity lithium battery, low power consumption design, can be used continuously for 24 hours after the battery is fully charged;
JGJ detection automatically generates thumbnails of on-site measurement points, and customizes the detection sequence;
Support the detection of concave-convex surface components, input the "surface circle diameter" to automatically compensate the deviation of the protective
layer, and select the cylindrical detection bracket to detect convex stirrups;
Support remote instrument software upgrade, enjoy convenient service support, PC-side software driver-free installation, data processing and report
generation can be easily completed.
